DC AXIAL FAN Series
General Specifications
• Motor:4 Poles brushless DC motor
• Frame & Impller:Plastic(UL 94V-0)
• Storage temperature: -40°to + 75°
• Operating temperature: -10°to + 75°
Major Characteristic Parameters
Specifications
|
Model |
Rated Voltage |
Operating Voltage range |
Rated Current |
Speed |
Air Flow |
Air Pressure |
Noise |
||
|
Part NO. |
V |
V |
A |
R.P.M |
CFM |
M³/min |
mmh2o |
inh2o |
dB.A |
|
WAD7015JG12S |
12 |
7.0~13.2 |
0.10 |
2800 |
21.1 |
0.60 |
2.3 |
0.09 |
27.0 |
|
WAD7015LG12S |
12 |
7.0~13.2 |
0.12 |
3300 |
25.7 |
0.73 |
3.3 |
0.13 |
31.0 |
|
WAD7015MG12S |
12 |
7.0~13.2 |
0.17 |
3800 |
29.6 |
0.84 |
4.3 |
0.17 |
35.0 |
|
WAD7015HG12S |
12 |
7.0~13.2 |
0.25 |
4300 |
33.5 |
0.95 |
5.5 |
0.22 |
39.0 |
• Bearing system B: Two Ball Bearing F:Fluild Bearing S:Sleeve Bearing
|
Air Flow and Static Pressure acteristics |
Unit:mm |
 |
 |
